Giant FASTROAD AR 1
Hurry up! Only 0 item(s) items left in stock
Couldn't load pickup availability
- Sku: 1041007123
- Available: Instock
- Collections: Bikes, Fitness Bikes, Giant, Hybrid Bikes
- Type: Hybrid Bike
Estimate delivery times: 3-5 days International.
Use code 'WELCOME15' for discount 15% on your first order.
Free shipping and returns: On all orders over $150.
Pairs well with
Giant FASTROAD AR 1 is made for rides where you want a dependable hybrid bike. It gives you a ready bike setup, so you can compare the frame, parts and size before you buy.
The main details to look at are Frame Material: ALUXX-Grade Aluminum 12x142mm thru-axle, Disc, Fork: Advanced-grade composite, OverDrive composite steerer, 12x100 mm thru-axle, disc, and Shifters: Shimano Cues U6000 11 speed - SLU60011R. These points help you quickly decide if this is the right choice for your bike, your fit, or the way you ride.
Key features
- Good for: rides where you want a dependable hybrid bike
- Brand: Giant
- Category: Hybrid Bikes
- Frame Material: ALUXX-Grade Aluminum 12x142mm thru-axle, Disc
- Fork: Advanced-grade composite, OverDrive composite steerer, 12x100 mm thru-axle, disc
- Shifters: Shimano Cues U6000 11 speed - SLU60011R
- Rear Derailleur: Shimano CUES
- Brakes: Tektro HD-R280 with Giant MPH rotors
- Check before buying: Check the frame size, wheel size and parts list to make sure it matches your height and riding style.
| Frame Material | ALUXX-Grade Aluminum 12x142mm thru-axle, Disc |
|---|---|
| Fork | Advanced-grade composite, OverDrive composite steerer, 12x100 mm thru-axle, disc |
| Shock | N/A |
| Shifters | Shimano Cues U6000 11 speed - SLU60011R |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano CUES |
| Brakes | Tektro HD-R280 with Giant MPH rotors |
| Crankset | FSA Omega AGX+, 42t |
| Component | Specification | Frame size(s) |
|---|---|---|
| Sizes | XS,S,M,L | |
| Colours | Electron Blue | |
| Frame Material | ALUXX-Grade Aluminum 12x142mm thru-axle, Disc | |
| Tire | Maxxis Re-Fuse 60 tpi 700x40C, Wirebead, Tubless | |
| Tire Size | 700x42C | |
| Tire Size - Measuring Unit | MM | |
| Fork | Advanced-grade composite, OverDrive composite steerer, 12x100 mm thru-axle, disc | |
| Headset | FSA No. 56E | |
| Front Derailleur | N/A | |
| Handlebar | Sport Flat, HL-MTB300BT, 0mm, 9 degree back sweep | |
| Seatpost | Giant D-Fuse, alloy, 350 mm | |
| Shifters | Shimano Cues U6000 11 speed - SLU60011R | |
| Rear Derailleur | Shimano CUES | |
| Grip | Giant ErgoContact | |
| Shock | N/A | |
| Crankset | FSA Omega AGX+, 42t | |
| Saddle | Giant ErgoContact | |
| Pedals | Platform pedals | |
| Brakes | Tektro HD-R280 with Giant MPH rotors | |
| Hubs | Giant S-X2 DIsc 700C Wheelset,12mm Thru Axles | |
| Cassette | Shimano CSLG40011 11x45 | |
| Brake levers | Tektro HD-R280 | |
| Chain | KMC X11 with Missing Link | |
| Rims | Giant S-X2 DIsc 700C Wheelset,12mm Thru Axles | |
| Bottom Bracket | BB-4000 | |
| Domestic Warranty | 1 |
| Size | Rider height |
|---|---|
| XS | 155-165 cm |
| S | 160-170 cm |
| M | 170-180 cm |
| XL | 190-200 cm |
| Measurement | XS | S | M | L | XL |
|---|---|---|---|---|---|
| A Seat Tube Length (mm) (inch) | 435 | 455 | 475 | 525 | 555 |
| B Seat Tube Angle (degrees) | 73.5° | 73.5° | 73.5° | 73.0° | 73.0° |
| C Top Tube Length (mm) (inch) | 545 | 560 | 575 | 610 | 630 |
| D Head Tube Length (mm) (inch) | 110 | 130 | 155 | 200 | 225 |
| E Head Tube Angle (degrees) | 70.5° | 70.5° | 71.0° | 71.5° | 71.5° |
| F Fork Rake (mm) (inch) | 50 | 50 | 50 | 50 | 50 |
| G Trail (mm) (inch) | 74 | 74 | 70 | 67 | 67 |
| H Wheelbase (mm) (inch) | 1031 | 1047 | 1058 | 1084 | 1105 |
| I Chain Stay Length (mm) (inch) | 435 | 435 | 435 | 435 | 435 |
| J Bottom Bracket Drop (mm) (inch) | 75 | 75 | 75 | 75 | 75 |
| K Stack (mm) (inch) | 533 | 552 | 578 | 623 | 646 |
| L Reach (mm) (inch) | 387 | 396 | 404 | 419 | 432 |
| M Stand Over Height (mm) (inch) | 718 | 736 | 756 | 800 | 826 |
| N Handlebar Width (mm) (inch) | 640 | 640 | 680 | 680 | 680 |
| O Stem Length (mm) (inch) | 70 | 80 | 90 | 100 | 110 |
| P Crank Length (mm) (inch) | 170 | 170 | 170 | 172.5 | 172.5 |
| Q Wheel Size | 700C | 700C | 700C | 700C | 700C |
