Marin Bobcat Trail 5 27.5
Hurry up! Only 0 item(s) items left in stock
Regular price
Rs. 74,999.00 INR
Couldn't load pickup availability
- Sku: 733942001
- Available: Instock
- Collections: Bikes, Marin, Mountain Bikes, Recreation & Sport Bikes
- Type: Mountain Bike
Estimate delivery times: 3-5 days International.
Use code 'WELCOME15' for discount 15% on your first order.
Free shipping and returns: On all orders over $150.
Guarantee Safe Checkout:
Pairs well with
Marin Bobcat Trail 5 27.5 is made for rides where you want a dependable mountain bike. It gives you a ready bike setup, so you can compare the frame, parts and size before you buy.
The main details to look at are Derailleur Rear: Shimano Deore RDM5100, 11-speed, w/Clutch, Crankset: Alloy Crank, Steel Narrow-Wide Chainring, 32T, and Cassette: Shimano CSM5100, 11-Speed, 11-51T. These points help you quickly decide if this is the right choice for your bike, your fit, or the way you ride.
Key features
- Good for: rides where you want a dependable mountain bike
- Brand: Marin
- Category: Mountain Bikes
- Derailleur Rear: Shimano Deore RDM5100, 11-speed, w/Clutch
- Crankset: Alloy Crank, Steel Narrow-Wide Chainring, 32T
- Cassette: Shimano CSM5100, 11-Speed, 11-51T
- Brake Front: Shimano BR-MT200 Hydraulic Disc, 180mm Rotor
- Rim: Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
- Check before buying: Check the frame size, wheel size and parts list to make sure it matches your height and riding style.
| Frame | Series 2 6061 Aluminum, 27.5" or 29” Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, IS Chainstay Disc Mount, Internal Housing & Dropper Post Routing |
|---|---|
| Front Suspension | SR Suntour XCR LOR-DS, Thru-Axle, 120mm Travel, Hydraulic Lockout, Damping Adjustment, 42mm (27.5") and 46mm (29") Offsets |
| Derailleur Rear | Shimano Deore RDM5100, 11-speed, w/Clutch |
| Crankset | Alloy Crank, Steel Narrow-Wide Chainring, 32T |
| Cassette | Shimano CSM5100, 11-Speed, 11-51T |
| Brake Front | Shimano BR-MT200 Hydraulic Disc, 180mm Rotor |
| Component | Specification | Frame size(s) |
|---|---|---|
| Frame | Series 2 6061 Aluminum, 27.5" or 29” Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, IS Chainstay Disc Mount, Internal Housing & Dropper Post Routing | |
| Front Suspension | SR Suntour XCR LOR-DS, Thru-Axle, 120mm Travel, Hydraulic Lockout, Damping Adjustment, 42mm (27.5") and 46mm (29") Offsets | |
| Rim | Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible | |
| Tires | Delium, Versatile, Triple Compound Tread, Tubeless-Compatible Wire Bead, 27.5/29x2.4" | |
| Derailleur Rear | Shimano Deore RDM5100, 11-speed, w/Clutch | |
| Crankset | Alloy Crank, Steel Narrow-Wide Chainring, 32T | |
| Bottom Bracket | Sealed Cartridge Bearings, Square Taper | |
| Cassette | Shimano CSM5100, 11-Speed, 11-51T | |
| Brakes Front | Shimano BR-MT200 Hydraulic Disc, 180mm Rotor | |
| Brakes Rear | Shimano BR-MT200 Hydraulic Disc, 180mm Rotor | |
| Handlebar | Marin 31.8 Riser, 12mm Rise, 780mm Width | |
| Stem | Marin Alloy, 31.8mm Clamp, 45mm | |
| Headset | FSA No.10-P | |
| Seatpost | Marin Alloy, 30.9 |
| Size | Rider height |
|---|---|
| Small | 163-170 cm |
| Medium | 173-178 cm |
| Large | 180-188 cm |
| XLarge | 190-190 cm |
| Measurement | Small | Medium | Large | XLarge |
|---|---|---|---|---|
| A Stack | 603 | 608 | 639 | 644 |
| B Reach | 445 | 455 | 475 | 495 |
| C Headtube angle | 66.5° | 66.5° | 66° | 66° |
| D Headtube length | 105 | 110 | 115 | 120 |
| E Seattube length | 381 | 431 | 482 | 520 |
| F Seattube angle | 74.5° | 74.5° | 74.5° | 74.5° |
| G Toptube effective | 612 | 623 | 652 | 673 |
| H Bb height | 307 | 307 | 311.5 | 311.5 |
| I Bb drop | 48 | 48 | 61 | 61 |
| J Chainstay | 415 | 415 | 430 | 430 |
| K Wheelbase | 1144 | 1156 | 1208 | 1230 |
| L Standover height | 640 | 690 | 732 | 760 |
| M Fork offset | 42 | 42 | 46 | 46 |
| N Seatpost diameter | 30.9 | 30.9 | 30.9 | 30.9 |
| O Handlebar width | 780 | 780 | 780 | 780 |
| P Stem length | 45 | 45 | 45 | 45 |
| Q Crank length | 170 | 170 | 170 | 170 |
