Marin DSX FS 700c
Hurry up! Only 0 item(s) items left in stock
Couldn't load pickup availability
- Sku: 733961001
- Available: Instock
- Collections: Bikes, Gravel & Adventure Bikes, Hybrid Bikes, Marin
- Type: Hybrid Bike
Estimate delivery times: 3-5 days International.
Use code 'WELCOME15' for discount 15% on your first order.
Free shipping and returns: On all orders over $150.
Pairs well with
Marin DSX FS 700c is made for rides where you want a dependable hybrid bike. It gives you a ready bike setup, so you can compare the frame, parts and size before you buy.
The main details to look at are Crankset: Forged Aluminum, 42T Steel Narrow Wide Chainring, Cassette: Shimano Deore, CSM6100, 12-Speed, 10-51T, and Brake Front: Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor. These points help you quickly decide if this is the right choice for your bike, your fit, or the way you ride.
Key features
- Good for: rides where you want a dependable hybrid bike
- Brand: Marin
- Category: Hybrid Bikes
- Crankset: Forged Aluminum, 42T Steel Narrow Wide Chainring
- Cassette: Shimano Deore, CSM6100, 12-Speed, 10-51T
- Brake Front: Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor
- Brake Rear: Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor
- Rim: Marin Aluminum Double Wall, 21mm Inner, Disc Specific, Tubeless Compatible
- Check before buying: Check the frame size, wheel size and parts list to make sure it matches your height and riding style.
| Frame | Series 3 DSX, Supension Adjusted Geometry, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle |
|---|---|
| Front Suspension | SR Suntour GVX LOR, 60mm Travel, Air Spring, Rebound Adjust, Lockout, Integrated Fender Mounts |
| Crankset | Forged Aluminum, 42T Steel Narrow Wide Chainring |
| Cassette | Shimano Deore, CSM6100, 12-Speed, 10-51T |
| Brake Front | Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor |
| Brake Rear | Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor |
| Component | Specification | Frame size(s) |
|---|---|---|
| Frame | Series 3 DSX, Supension Adjusted Geometry, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle | |
| Front Suspension | SR Suntour GVX LOR, 60mm Travel, Air Spring, Rebound Adjust, Lockout, Integrated Fender Mounts | |
| Rim | Marin Aluminum Double Wall, 21mm Inner, Disc Specific, Tubeless Compatible | |
| Hub Rear | Forged Aluminum, 142x12mm, Disc Specific, 32H | |
| Hub Front | Forged Aluminum, 100x12mm, Disc Specific, 32H | |
| Tires | Vee Tire Co., QuikStyk, 700x45, Folding Bead, Tubeless Compatible | |
| Crankset | Forged Aluminum, 42T Steel Narrow Wide Chainring | |
| Cassette | Shimano Deore, CSM6100, 12-Speed, 10-51T | |
| Brakes Front | Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor | |
| Brakes Rear | Shimano BR-MT201/R300, Hydraulic, Flat Mount, 160mm Rotor | |
| Headset | FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” | |
| Seatpost | TranzX YSP38J, Size S 70mm, Size M-XL 110mm Travel, 27.2mm |
| Size | Rider height |
|---|---|
| S | 165-173 cm |
| M | 175-190 cm |
| XL | 193-193 cm |
| Measurement | Small | Medium | Large | XLarge |
|---|---|---|---|---|
| A Stack | 583.2 | 601.8 | 629.7 | 657.6 |
| B Reach | 400 | 425 | 440 | 455 |
| C Headtube angle | 68.5° | 68.5° | 68.5° | 68.5° |
| D Headtube length | 100 | 120 | 150 | 180 |
| E Seattube length | 430 | 480 | 520 | 558 |
| F Seattube angle | 74° | 74° | 74° | 74° |
| G Toptube effective | 567.23 | 597.6 | 620.6 | 643.6 |
| H Bb height | 277.5 | 277.5 | 277.5 | 277.5 |
| I Bb drop | 82 | 82 | 82 | 82 |
| J Chainstay | 425 | 425 | 425 | 425 |
| K Wheelbase | 1065 | 1097.3 | 1123.3 | 1149.3 |
| L Standover height | 667 | 708 | 738 | 741.7 |
| M Fork offset | 47 | 47 | 47 | 47 |
| N Seatpost diameter | 27.2 | 27.2 | 27.2 | 27.2 |
| O Handlebar width | 680 | 680 | 680 | 700 |
