Polygon SYNCLINE C2
Hurry up! Only 0 item(s) items left in stock
Regular price
Rs. 0.00 INR
Couldn't load pickup availability
- Sku: 502636001
- Available: Instock
- Collections: Bikes, Mountain Bikes, Polygon
- Type: Mountain Bike
Estimate delivery times: 3-5 days International.
Use code 'WELCOME15' for discount 15% on your first order.
Free shipping and returns: On all orders over $150.
Guarantee Safe Checkout:
Pairs well with
Polygon SYNCLINE C2 is made for rides where you want a dependable mountain bike. It gives you a ready bike setup, so you can compare the frame, parts and size before you buy.
The main details to look at are Frameset: ACX XC PERFORMANCE, Fork: SUNTOUR XCR 32 LO-R, 120mm TRAVEL, and Crank: SHIMANO DEORE FC-M5100 32T. These points help you quickly decide if this is the right choice for your bike, your fit, or the way you ride.
Key features
- Good for: rides where you want a dependable mountain bike
- Brand: Polygon
- Category: Mountain Bikes
- Frameset: ACX XC PERFORMANCE
- Fork: SUNTOUR XCR 32 LO-R, 120mm TRAVEL
- Crank: SHIMANO DEORE FC-M5100 32T
- Cassette: 12 SPEED 11-51T
- Rear Derailleur: SHIMANO DEORE RD-M5100
- Check before buying: Check the frame size, wheel size and parts list to make sure it matches your height and riding style.
| Frameset | ACX XC PERFORMANCE |
|---|---|
| Fork | SUNTOUR XCR 32 LO-R, 120mm TRAVEL |
| Crank | SHIMANO DEORE FC-M5100 32T |
| Cassette | 12 SPEED 11-51T |
| Rear Derailleur | SHIMANO DEORE RD-M5100 |
| Shifter | SHIMANO DEORE SL-M5100, 1x11 SPEED |
| Brake Lever | SHIMANO MT200 HYDRAULIC DISC BRAKE |
| Brake Caliper | SHIMANO MT200 HYDRAULIC DISC BRAKE |
| Component | Specification | Frame size(s) |
|---|---|---|
| Frameset | ACX XC PERFORMANCE | |
| Fork | SUNTOUR XCR 32 LO-R, 120mm TRAVEL | |
| Rear Shock | - | |
| Shifter | SHIMANO DEORE SL-M5100, 1x11 SPEED | |
| Crank | SHIMANO DEORE FC-M5100 32T | |
| Cassette | 12 SPEED 11-51T | |
| Rear Derailleur | SHIMANO DEORE RD-M5100 | |
| BB | SHIMANO MT500 | |
| Chain | KMC X11-1 | |
| Saddle | ENTITY VOID SADDLE | |
| Seatpost | ENTITY XPERT, ALLOY | |
| Handlebar | ENTITY XPERT, ALLOY | |
| Handlestem | ENTITY XPERT, ALLOY | |
| Headset | THREADLESS INTEGRATED HEADSET | |
| Wheel Set | ALLOY DOUBLE WALL 32H | |
| Wheel Size | 27.5" / 29" | |
| Tire | WTB TRAIL BOSS 27.5"x2.25" / 29"x2.25" | |
| Rim | 584-22 / 622-22 32H FOR TYRE 584 / 622-35/68 | |
| Brake Lever | SHIMANO MT200 HYDRAULIC DISC BRAKE | |
| Brake Caliper | SHIMANO MT200 HYDRAULIC DISC BRAKE | |
| Rotor | FRONT:180mm REAR:160mm CENTER-LOCK |
| Size | Rider height (cm) |
|---|---|
| S (27.5”) | 155-165 |
| M (27.5”) | 165-175 |
| M (29”) | 165-175 |
| L (29”) | 175-185 |
| XL (29”) | 185-195 |
| Measurement | S (27.5”) | M (27.5”) | M (29”) | L (29”) | XL (29”) |
|---|---|---|---|---|---|
| Height (cm) | 155-165 | 165-175 | 165-175 | 175-185 | 185-195 |
| A Seat Tube Length | 380 | 420 | 420 | 460 | 500 |
| B Seat Tube Angle | 73 | 73 | 73 | 73 | 73 |
| C Effective Seat Tube Angle | 75.3 | 75.3 | 75.3 | 75.3 | 75.3 |
| D Head Tube Length | 100 | 120 | 100 | 120 | 140 |
| E Head Tube Angle | 67 | 67 | 67 | 67 | 67 |
| F Effective Top Tube | 569 | 594.6 | 597.7 | 621 | 649.15 |
| G Bb Height | 308.5 | 308.5 | 307.5 | 307.5 | 307.5 |
| H Bb Offset | 45 | 45 | 65 | 65 | 65 |
| I Chainstay Length | 425 | 425 | 435 | 435 | 435 |
| J Wheelbase | 1106.94 | 1134.8 | 1149.5 | 1176.9 | 1204.76 |
| K Frame Reach | 410 | 430 | 430 | 450 | 470 |
| L Frame Stack | 596.6 | 615 | 633.2 | 651.6 | 670 |
| M Standover Height | 690.9 | 729.2 | 730.8 | 763.7 | 779.2 |
