Trek FX Sport SL 5
Trek FX Sport SL 5 is a hybrid bike tuned for fitness rides, commuting and everyday road use. The platform is built around a Carbon frame paired with a Carbon fork, so the ride feel stays composed,...
Hurry up! Only 0 item(s) items left in stock
Regular price
Rs. 171,199.00 INR
Couldn't load pickup availability
- Sku: 5324000
- Available: Instock
- Collections: Bikes, Fitness Bikes, Hybrid Bikes, Trek
- Type: Hybrid Bike
Estimate delivery times: 3-5 days International.
Use code 'WELCOME15' for discount 15% on your first order.
Free shipping and returns: On all orders over $150.
Guarantee Safe Checkout:
Pairs well with
Trek FX Sport SL 5 is made for rides where you want a dependable hybrid bike. It gives you a ready bike setup, so you can compare the frame, parts and size before you buy.
The main details to look at are Frame: Carbon, Fork: Carbon, and Tyres: Bontrager GR1 Expert. These points help you quickly decide if this is the right choice for your bike, your fit, or the way you ride.
Key features
- Good for: rides where you want a dependable hybrid bike
- Brand: Trek
- Category: Hybrid Bikes
- Frame: Carbon
- Fork: Carbon
- Tyres: Bontrager GR1 Expert
- Drivetrain: SRAM Apex
- Brakeset: Shimano hydraulic disc
- Check before buying: Check the frame size, wheel size and parts list to make sure it matches your height and riding style.
| Frame | Carbon |
|---|---|
| Fork | Carbon |
| Tyres | Bontrager GR1 Expert |
| Drivetrain | SRAM Apex |
| Brakeset | Shimano hydraulic disc |
| Weight | M – 10.30 kg/22.71 lb |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
| Component | Specification | Frame size(s) |
|---|---|---|
| Chain | KMC X11 | S, M, L, XL |
| Frame | 400 series OCLV Carbon, internal routing, 3s chain keeper, DuoTrap S compatible, mudguard mounts, flat mount disc, 135x5 mm ThruSkew | S, M, L, XL |
| Fork | Carbon, hidden mudguard mounts, flat mount disc, 100x5 mm thru-skew | S, M, L, XL |
| Headset part (see also: Bearing) | Bontrager Headset Expander Plug and Top Cap | S, M, L, XL |
| Hub rear | Formula CL-52 alloy, 135x5 mm | S, M, L, XL |
| Hub front | Formula CL-51 alloy, 100x5 mm | S, M, L, XL |
| Crank | Prowheel alloy, 42T narrow-wide ring, 175 mm length | S, M, L, XL |
| Pedal | Bontrager City pedals | S, M, L, XL |
| Stem | Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length | S, M |
| Stem | Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length | L, XL |
| Saddle | Bontrager Montrose Comp, steel rails, 138 mm width | S, M, L, XL |
| Handlebar | Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 600 mm width | S |
| Handlebar | Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 660 mm width | M, L, XL |
| Tyre | Bontrager GR1 Expert, Hard-Case Lite, wire bead, 60 tpi, 700x40 c | S, M, L, XL |
| Bearing | 1.5", sealed cartridge bearing | S, M, L, XL |
| Rear derailleur | SRAM Apex 1, long cage, 42T max cog | S, M, L, XL |
| Seatpost | Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length | S, M, L, XL |
| Cassette | microSHIFT XLE, 11-42, 11-speed | S, M, L, XL |
| Rim | Bontrager Paradigm, Tubeless Ready, 32-hole, 21 mm width, Presta valve | S, M, L, XL |
| Brake rotor | Shimano RT10, CenterLock, 160 mm | S, M, L, XL |
| Shifter | SRAM Apex, 11-speed | S, M, L, XL |
| Grips | Bontrager Satellite IsoZone Plus, lock-on, ergonomic | S, M, L, XL |
| Brake | Shimano hydraulic disc, MT201 lever, UR300 calliper | S, M, L, XL |
| Skewer front | 135x5 mm bolt-on | S, M, L, XL |
| Skewer rear | 169x5 mm bolt-on | S, M, L, XL |
| Size | Rider height | Inseam |
|---|---|---|
| XS | 4'10" - 5'1" / 147 - 155 cm | 27" - 29" / 69 - 73 cm |
| S | 5'1" - 5'5" / 155 - 165 cm | 28" - 31" / 72 - 78 cm |
| M | 5'5" - 5'9" / 165 - 175 cm | 30" - 33" / 77 - 83 cm |
| L | 5'9" - 6'1" / 175 - 186 cm | 32" - 35" / 82 - 88 cm |
| XL | 6'1" - 6'6" / 186 - 197 cm | 34" - 37" / 87 - 93 cm |
| Measurement | S | M | L | XL |
|---|---|---|---|---|
| Wheel size | 700c | 700c | 700c | 700c |
| A Seat tube | 40.6 | 45.7 | 50.8 | 55.9 |
| B Seat tube angle | 74.5° | 74.0° | 73.5° | 72.5° |
| C Head tube length | 14.0 | 16.5 | 19.0 | 21.5 |
| D Head tube angle | 70.5° | 71.0° | 71.5° | 72.5° |
| E Top tube effective | 54.3 | 56.3 | 58.3 | 61.3 |
| F BB height | 28.5 | 28.5 | 28.5 | 28.5 |
| G BB drop | 6.5 | 6.5 | 6.5 | 6.5 |
| H Chainstay | 44.2 | 44.2 | 44.2 | 44.2 |
| I Fork offset | 5.0 | 5.0 | 5.0 | 5.0 |
| J Trail | 7.1 | 6.8 | 6.4 | 5.8 |
| K Wheelbase | 105.4 | 106.5 | 107.5 | 108.2 |
| L Standover | 75.1 | 78.7 | 81.2 | 84.8 |
| M Reach | 38.5 | 39.3 | 40.0 | 41.0 |
| N Stack | 56.8 | 59.4 | 62.0 | 64.8 |
